Xiegu VG-4 4-Band Portable HF Vertical Antenna

Xiegu VG-4 – 4-Band Portable Vertical Antenna for HF Ham Radio (7/14/21/28 MHz)

The Xiegu VG-4 is a compact and lightweight portable vertical antenna designed for HF amateur radio operation on four key ham bands: 40m, 20m, 15m, and 10m (7, 14, 21, and 28 MHz). It’s the perfect companion for field use, portable setups, and temporary base stations—especially when paired with radios like the Xiegu G90, X6100, or other QRP rigs.

Specifications:

• Model: VG-4

• Bands Supported: 40m, 20m, 15m, 10m (7/14/21/28 MHz)

• Antenna Type: Vertical whip with multiple band traps

• Power Handling: Up to 100W SSB (lower for digital modes)

• Impedance: 50 Ohms

• Connector: Standard PL-259/SO-239 base

• Length: Approx. 8–10 ft assembled

• Tuning: Pre-tuned with minor adjustments if needed

• Portability: Disassembles for easy transport/storage

• Recommended Use: QRP, portable HF, emergency comms, RV, field day

Features:

• Supports 4 primary HF amateur bands with single feed point

• No tuner required when properly deployed and matched

• Lightweight, modular construction for fast field deployment

• Great for backpacking, POTA/SOTA, and emergency operation

• Compatible with Xiegu and other HF/QRP transceivers

The VG-4 offers reliable performance and unmatched convenience for hams needing quick-deploy vertical coverage in a compact package.
